LUEN-10-10A
LUEN
8716100000
5600
| Material: | Please select |
|---|---|
| Size: | Please select |
| Axle Number: | Please select |
| Suspension: | Please select |
| Quantity: | |
| Brand | LUEN |
| Loading Type | Top manhole loading |
| Overall Dimensions(mm) | Approximate :11200*2500* 3900 |
| GVW(kg) | Approximate :40000 |
| Rated Loading(kg) | Approximate :33000 |
| Tank | |
| Actual Loading capacity | 39.5CBM+5% (Volume filled with water) |
| Tank /Thickness | 7mm |
| End /Thickness | 7mm |
| Tank Storehouse Number | 2-3 |
| Frame And Accessories | |
| Main Beam | Manganese steel, 450/12-10-14 |
| Side Guard | Carbon steel |
| Rear Bumper | Carbon steel, rear double bumper |
| Toolbox | 1 |
| Walking Mechanism | |
| Axles | 13T*3 Axle /Equipped with ABS system |
| Suspension | Mechanical Suspension13T * 3 |
| Tire | 12.00R22.5 *12 |
| King Pin | 90# or 50# |
| Landing Leg | 28T |
| The above configuration can be adjusted according to customer requirements, and can be equipped with Fuwa PBW axle and air suspension. | |
| Brand | LUEN |
| Loading Type | Top manhole loading |
| Overall Dimensions(mm) | Approximate :11200*2500* 3900 |
| GVW(kg) | Approximate :40000 |
| Rated Loading(kg) | Approximate :33000 |
| Tank | |
| Actual Loading capacity | 39.5CBM+5% (Volume filled with water) |
| Tank /Thickness | 7mm |
| End /Thickness | 7mm |
| Tank Storehouse Number | 2-3 |
| Frame And Accessories | |
| Main Beam | Manganese steel, 450/12-10-14 |
| Side Guard | Carbon steel |
| Rear Bumper | Carbon steel, rear double bumper |
| Toolbox | 1 |
| Walking Mechanism | |
| Axles | 13T*3 Axle /Equipped with ABS system |
| Suspension | Mechanical Suspension13T * 3 |
| Tire | 12.00R22.5 *12 |
| King Pin | 90# or 50# |
| Landing Leg | 28T |
| The above configuration can be adjusted according to customer requirements, and can be equipped with Fuwa PBW axle and air suspension. | |
